Head Trauma

Head Trauma. Neurologic Evaluation. X-ray CT MRI Angiography. Right occipital fracture. Linear lucency representing linear skull fracture. Depressed Skull Fracture. Epidural Hematoma. Lenticular vascular void adjacent to the parietal bone on angiography. High density area

havily
Télécharger la présentation

Head Trauma

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Head Trauma

  2. Neurologic Evaluation • X-ray • CT • MRI • Angiography

  3. Right occipital fracture • Linear lucency representing linear skull fracture

  4. Depressed Skull Fracture

  5. Epidural Hematoma • Lenticular vascular void adjacent to the parietal bone on angiography

  6. High density area Lens shaped Right parietal Confined to sutures Epidural Hematoma

  7. Subdural Hematoma • Balanced (upper image) and T2 image • Band like high signal along right lateral brain surface • Crescentic shape • Represents methemoglobin resulting from subdural bleed • Compare to epidural

  8. Acute Subdural Hematoma • High attenuation collection crossing sutures • Mass effect with midline shift

  9. Chronic Subdural • Crescentic high signal bilaterally larger on the right • Represents chronic subdural bleeding

  10. Subdural – Epidural Compared

  11. Parenchymal Bleed • Intraparenchymal hematoma • No enhancement • Deep left parietal white matter • Oval high attenuation (blood) • Surrounding low attenuation (edema) • Mild mass effect

  12. Subdural – Epidural – ParenchymalCompared
