Presentation Transcript

  1. Chapter 15 The Skeletal System

  2. Functions • Act as the framework of the body • Support and protect some of the internal organs • Contains and protects the red bone marrow • Provides a storage site for excess calcium

  3. Structures of the Skeletal System • Bones • Cartilage • Ligaments • Joints • Bursae

  4. Bones • Related Combining Forms • oss/e, oss/i • oste/o, ost/o • Tissues • Periosteum (peri- means surrounding) • Compact Bone – forms outer layer of bones • Spongy Bone – found inside bones – makes them lighter and contains red bone marrow • Endosteum – lines the medullary cavity

  5. Classification of Bones • Long • Longer than they are wide • The shaft is hollow and contains yellow bone marrow • Examples include the bones of the upper and lower extremities (except for the wrists and ankles)

  6. Classification of Bones • Short • Roughly cuboidal • Comprised mostly of spongy bone with a thin covering of compact bone • Examples: Wrist, ankle, kneecap

  7. Classification of Bones • Flat • Made of a thin layer of spongy bone sandwiched between layers of compact bone • Spongy bone usually contains red bone marrow • Used to protect internal organs • Examples: skull, ribs, etc

  8. Classification of Bones • Irregular • Includes bones that do not fit into any of the previous categories • Composed of spongy bone with a thin layer of compact bone on the outside • Red bone marrow is contained in the spongy bone • Examples: vertebrae, facial bones, etc

  9. Anatomical Landmarks • Diaphysis • Shaft of a long bone • Epiphysis • Wide end of a long bone (covered with articular cartilage) • Can be identified as proximal or distal • Foramen • Opening in the bone through which structures can pass (ex blood vessels, nerves, etc) • Process • Normal projection on the surface of a bone that serves as an attachment for tendons and ligaments

  10. Bone Marrow • Primary Functions • Red bone marrow forms red and white blood cells and platelets • Stem cells • Makes up all the marrow in an infant • Yellow bone marrow stores fat • Replaces part of the red bone marrow in mature humans • Related Combining Form • myel/o(also means spinal cord)

  11. Cartilage • Functions as a shock absorber and a structural element • Creates a smooth surface for motion within the joints. • Protects the ends of the bones. • Chondr/o means cartilage • 3 types • Hyaline • Elastic • Fibrocartilage

  12. Cartilage • Hyaline cartilage covers the ends of bones where they join to provide a smooth surface • AKA Articular cartilage • Elastic Cartilage is found in the ear and in the larynx • Fibrocartilage is found between the vertebrae and where ligaments and tendons join to bone

  13. Ossification • Process by which cartilage in the fetus is changed into bone • Bone matrix is produced by osteoblasts (-blast means embryonic cell) • Process begins at the center of ossification (center) of the bone • long bones also have centers of ossification in their epiphyses • Osteoclasts reabsorb bone matrix in the interior of the bones (-clast means break down)

  14. Ligaments • Tough bands of fibrous connective tissue that link bones, cartilages, or other body structures together • In the skeletal system, ligaments hold bones together at joints to prevent dislocation or excessive movement • Ligament/omeans ligament

  15. Joints • AKA Articulations • Connections between bones • Some allow bones to move, some do not • Arthr/oandarticul/o bothmean joint

  16. Types of Joints • Suture • Formed when bones are very close togther • Only separated by fibrous connective tissue • Immovable • Most common in the skull where the cranial bones meet • Formed when the fontanels present in the infant’s skull are ossified

  17. Types of Joints • Symphysis • Two bones joined together with cartilage to function as one bone • Only slightly movable • Example: pubic symphysis, vertebrae, ribs to sternum

  18. Types of Joints • Synovial • Two bones held in proximity by ligaments • Synov/o, synovi/o • Movable • Come in different types • Ball and socket – wide range of movement in any direction (hips, shoulders) • Hinge – movement primarily in one direction (elbows, knees, etc) • Covered by a fibrous capsule and a synovial membrane that secretes synovial fluid

  19. Bursae • Primary Function • Cushions areas of joints that are subject to friction during movement. • Basically a fluid-filled sac located between the skin and joint • Related Combining Form • burs/o

  20. Skeleton • 206 Bones in the adult human body • To help organize, the bones are divided into the Axial and Appendicular Skeleton • Axial • 80 bones • Consists of the skull, spine, ribs and sternum • Appendicular • 126 bones • Consists of the bones of the upper and lower extremities

  21. Axial Skeleton • Skull • Made up of 8 cranial bones, 14 facial bones, and 6 auditory ossicles • Cranial bones • Protect the brain (crani/o means skull) • Frontal (forehead) • 2 Parietal (roof and sides of skull) • Occipital (floor and back of the skull) • 2 Temporal (sides and part of the base) • Sphenoid (part of the base of the skull, floor and sides of the orbit) • Ethmoid (part of the nose, orbit and cranium)

  22. Axial Skeleton • Auditory Ossicles • Malleus, Incus, Stapes (x2)

  23. Axial Skeleton • Facial Bones • 2 Nasal bones (bridge of nose) • 2 Zygomatic bones (cheekbones) • 2 Maxillae (upper jaw) • 2 Palatine bones (part of the hard palate and floor of the nose) • 2 Lacrimal bones (inner corner of orbit) • 2 Inferior Chonchae (interior of nose • Vomer (nasal septum) • Mandible (lower jaw – only movable bone of the skull) • Temporomandibular joint (TMJ)

  24. Axial Skeleton • Thoracic Cage • 25 bones • Sternum • AKA breastbone • Form the center of the anterior chest wall • 3 parts • Manubrium –upper part of the sternum • Body – middle of the sternum • Xiphoid process – cartilage, lower part of sternum

  25. Axial Skeleton • Ribs • Protect the lungs, heart, liver, spleen • AKA Costals (cost/o means rib) • 12 pairs • First 7 pairs are called true ribs because they are attached anteriorly to the sternum • Next 3 pairs are false ribs because they do not directly attach to the sternum, but they do attach to the cartilage that joins to the sternum • Last 2 pairs are called floating ribs because they are not attached anteriorly

  26. Axial Skeleton • Vertebral Column • Supports the head and protects the spinal cord • Vertebr/o, spondyl/omean vertebrae • Rachi/o, rach/i, spin/omean spine • Bodies of adjacent vertebrae are separated by discs of fibrocartilage (symphysis joints)

  27. Axial Skeleton • 26 vertebrae • Cervical vertebrae – first 7, form the neck (cervic/o means neck) • C1 is known as the atlas, C2 is known as the axis • Thoracic vertebrae – 12, form the upper back • Lumbar vertebrae – 5, form the lower back • Sacrum – triangular shaped, forms the lower, lower back (5 bones fused in childhood) • Coccyx – tailbone, end of spine (4 small vertebrae that fuse together)

  28. Appendicular Skeleton • Upper Extremities • Pectoral Girdle • Clavicle – collarbone, connects manubrium to scapula (clavicul/o) • Most frequently fractured bone in the body • Scapula – shoulder blade (scapul/o) • Acromion – extension of the scapula that forms the high point of the shoulder

  29. Appendicular Skeleton • Arms • Humerus – upper arm (humer/o) • Radius – lateral side of forearm (smaller bone) (radi/o) • Ulna – medial side of forearm (uln/o) • Olecranon process – projection of ulna that forms the point of the elbow (funny bone)

  30. Appendicular Skeleton • Wrist and Hand • AKA Carpus (carp/o means wrist) • 8 short bones known as carpals • 5 metacarpals (meta- means next) • Form the palm of the hand • 28 phalanges (phalang/o) • Singular: phalanx • Fingers have 3 phalanges (distal, medial, proximal) • The thumb has 2 phalanges (distal and proximal)

  31. Appendicular Skeleton • Pelvic Girdle • Forms the pelvic cavity (pelv/i means pelvis) • 2 pubic bones, each with 3 parts • Ilium – broad, flat bone (ili/o) • Ischium – lower posterior portion of the pubic bone (ischi/o) • Pubis – forms the anterior portion of the pubic bone (pub/o) • The two bones join at the pubic symphysis and connect with the sacrum at the sacroiliac joint • The lower extremity joins to the pelvic bone at the acetabulum (hip socket)

  32. Appendicular Skeleton • Legs • Femur – thigh bone • Largest, strongest bone in the human body • Femor/o • Patella – kneecap • Popliteal is a term used to describe the posterior surface of the knee (patell/o) • Tibia – shinbone, forms the anterior of the lower leg (tibi/o) • Fibula – smaller bone of the lower leg (fibul/o)

  33. Appendicular Skeleton • Ankles and Feet • AKA Tarsus (tars/o means ankle) • 5 short bones called tarsals • Ex calcaneus or heel bone • 5 metatarsals form the body of the foot • Each toe is made up of 3 phalanges, except for the big toe (hallux), which only has 2
