Development of a CO2 Laser-Based Polarized Positron Source Using Compton Scattering

jalene avatar
jalene
23 diapositives · 363 Views · Aug 09, 2014

This paper discusses the concept of a polarized positron source utilizing a picosecond CO2 laser pulse within a ring cavity. Through Compton scattering, the laser interacts with a counter-propagating electron pulse, producing γ-quanta. Key parameters such as pulse duration, energy, and frequency are optimized for enhanced γ-yield compared to conventional systems. The study encompasses simulation results, pulse dynamics, and early tests of the Linac Compton Source (LCS). The potential for achieving high-efficiency positron generation to meet future collider demands is highlighted.

#development of a co2 laser-based polarized positron source using compton scattering #development of a co2 laser-based polarized positron source using compton scattering ppt #powerpoint #presentation
Development of a CO2 Laser-Based Polarized Positron Source Using Compton Scattering - slide 1
01 / 23Development of a CO2 Laser-Based Polarized Positron Source Using Compton Scattering
1 / 17

Télécharger la présentation

Development of a CO2 Laser-Based Polarized Positron Source Using Compton Scattering
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Compton Linacfor Polarized Positrons V. Yakimenko, I. Pogorelsky, M. Polyanskiy, M. Fedurin BNL CERN, October 15, 2009

  2. Polarized positron source: the concept - A picosecond CO2 laser pulse circulates in a ring cavity - At each pass through the cavity the laser pulse interacts with a counter-propagating electron pulse generating γ-quanta viaCompton scattering - Optical losses are compensated by intracavity amplifier - The λ-proportional number of photons per Joule of laser energy allows for higher γ-yield (compared to solid state lasers) CO2amplifier Metallic target Interaction point Pulse duration: 5 ps Pulse energy: 1J Repetition: 3-12 ns Pulses/bunch: 100

  3. Polarized positron source  to e+ conv. target 60MeV  beam 6GeV e- beam 30MeV e+ beam ~2 m 3% over 1 s Conventional Non-Polarized Positrons: Polarized γ-ray beam is generated in the Compton back scattering inside optical cavity of CO2 laser beam and 6 GeV e-beam produced by linac. First tests of the laser cavity

  4. Linac Compton Source (LCS): Numbers

  5. Computer simulations: Model Beam Propagation (diffraction, optics, losses) Amplification & Rotational relaxation (fast time-scale) Vibrational relaxation (slow time-scale) Boltzmann equations (discharge energy distribution) Discharge dynamics Pumping (slow time-scale) Spectra (amplification band) Using data from HITRAN2008

  6. Simulation results O16:O18 = 50:50 Natural CO2 Pulse energy dynamics

  7. Simulation results O16:O18 = 50:50 Natural CO2 Pulse energy dynamics Gain spectra

  8. Simulation results O16:O18 = 50:50 Natural CO2 Pulse energy dynamics Pulse spectra (initial and after reaching 1 J)

  9. Simulation results Natural CO2 O16:O18 = 50:50 Pulse energy dynamics Pulse spectra (initial and after reaching 1 J) Temporal pulse profile (initial and after reaching 1 J)

  10. Pulse diagnostics Diffractive grating Pyrocamera Mixing crystal Pyrocamera Filter Streak camera CO2 10μm 1.3 cm-1 0.8 μm Measured Simulated Laser diode 0.9 μm wavenumber 25 ps Measured Simulated time “Streak camera” “Spectrometer” “Interferometer” Fourier transform Δt = 0 5 ps 10 ps Individual pulse Fourier transform Total bandwidth <=> Individual pulse sub-ps resolution Individual lines <=> Train resolution improvement needed 25 ps 50 ps 75 ps Train :) Single-shot :) Simple = reliable :)Indiv. pulse measurements ... Train measurements (?) :( Indirect method :( Multiple-shot :)Indiv. pulse measurements :) Train measurements :( Complicated data analysis :) Single-shot :( Low resolution (~10 ps ) :) Train measurements

  11. Laser system

  12. Possible configuration with 5 IPs and 1 laser amplifier ~15 cm ~1m

  13. Wall plug power consideration • ILC: • 3 1014 positrons/second; • 2% g - > e+ efficiency for 60 MeVg => 150 kW g beam • Wall plug to g for warm linac/CO2 is expected ~5-10%

  14. Cross section for Pair production

  15. Positron generation efficiency

  16. Angular spread of positron beam

  17. Positron beam size at the target exit

  18. Normalized emittance at the target exit

  19. Positron generation efficiency normalized by emittance

  20. Positron generation efficiency normalized by emittance and gamma beam power

  21. Positron generation efficiency normalized by transverse phase space

  22. Positron generation efficiency normalized by transverse phase space and gamma beam power

  23. Conclusion • Polarized positron beam requirement for CLIC can be satisfied with Compton CO2/LINAC based gamma source • Higher energy gamma beam is preferential for the thermal load on the target • Shorter target is preferential when low emittance after target is needed (CLIC, LeHC …) • Total power consumption should be part of optimization for high positron demands (LeHC) • Amplification in Isotope mixture will be tested shortly at ATF • Seed pulse generation using solid state laser will be tested at ATF in ~year • There is no funding/activity for regenerative cavity test
