Review: Volumes of Revolution

Review: Volumes of Revolution. y. x. If we let h equal the height of the slice then the volume of the slice is:. h. 45 o. x. A 45 o wedge is cut from a cylinder of radius 3 as shown. Find the volume of the wedge.

lynnea
Télécharger la présentation

Review: Volumes of Revolution

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Review: Volumes of Revolution

  2. y x If we let h equal the height of the slice then the volume of the slice is: h 45o x A 45o wedge is cut from a cylinder of radius 3 as shown. Find the volume of the wedge. You could slice this wedge shape several ways, but the simplest cross section is a rectangle. Since the wedge is cut at a 45o angle: Since

  3. y x Even though we started with a cylinder, p does not enter the calculation!

  4. Cavalieri’s Theorem: Two solids with equal altitudes and identical parallel cross sections have the same volume. Identical Cross Sections p

  5. 7.3 Disk and Washer Methods

  6. The natural draft cooling tower shown at left is about 500 feet high and its shape can be approximated by the graph of this equation revolved about the y-axis: The volume can be calculated using the disk method with a horizontal disk.

  7. The volume of the washer is: The region bounded by and is revolved about the y-axis. Find the volume. If we use a horizontal slice: The “disk” now has a hole in it, making it a “washer”. outer radius inner radius

  8. The washer method formula is: This application of the method of slicing is called the washer method. The shape of the slice is a circle with a hole in it, so we subtract the area of the inner circle from the area of the outer circle.

  9. Washer Cross Section The region in the first quadrant enclosed by the y-axis and the graphs of y = cosx and y = sin x is revolved about the x-axis to form a solid. Find its volume.

  10. Washer Cross Section The region in the first quadrant enclosed by the y-axis and the graphs of y = cos x and y = sin x is revolved about the x-axis to form a solid. Find its volume.

  11. 7.3 The Shell Method

  12. Find the volume generated when this shape is revolved about the y axis. We can’t solve for x, so we can’t use a horizontal slice directly.

  13. If we take a vertical slice and revolve it about the y-axis we get a cylinder. Shell method:

  14. Note: When entering this into the calculator, be sure to enter the multiplication symbol before the parenthesis.

  15. When the strip is parallel to the axis of rotation, use the shell method. When the strip is perpendicular to the axis of rotation, use the washer method. p

  16. Volumes Using Cylindrical Shells The region bounded by the curve y = , the x-axis, and the line x = 4 is revolved about the x-axis to generate a solid. Find the volume of the solid using cylindrical shells.

  17. Volumes Using Cylindrical Shells The region bounded by the curve y = , the x-axis, and the line x = 4 is revolved about the x-axis to generate a solid. Find the volume of the solid using cylindrical shells.
