More-than-Moore Roadmapping Update

DESCRIPTION

The More-than-Moore approach emphasizes functional diversification, enabling the integration of non-digital functionalities into devices that enhance value beyond traditional scaling of digital capabilities. This roadmap addresses the integration of "More Moore" (MM) with "More than Moore" (MtM), supporting the creation of compact, heterogeneous systems. The ITRS conference in San Francisco discusses the importance of roadmapping for CMOS technology, identifying research domains, reducing development costs, and synchronizing the electronics community to foster innovation in diversified functionalities like sensors, actuators, and biochips.

1 / 10

Télécharger la présentation

More-than-Moore Roadmapping Update

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. More-than-Moore RoadmappingUpdate ITRS public conference – San Francisco

  2. More Moore & More than Moore: Definitions • “More Moore”: ScalingContinued shrinking of physical feature sizes of the digital functionalities (logic and memory storage) in order to improve density (cost per function reduction) and performance (speed, power). • “More than Moore”: Functional DiversificationIncorporation into devices of functionalities that do not necessarily scale according to "Moore's Law“, but provide additional value in different ways. The "More-than-Moore" approach allows for the non-digital functionalities to migrate from the system board-level into the package (SiP) or onto the chip (SoC).  • The Challenge: Integration of MM with MtMCreation of heterogeneous compact systems. ITRS public conference – San Francisco

  3. More than Moore: Diversification Analog/RF Passives HV Power Sensors Actuators Biochips Interacting with people and environment Non-digital content System-in-package (SiP) 130nm 90nm Baseline CMOS: CPU, Memory, Logic 65nm Information Processing Digital content System-on-chip (SoC) Combining SoC and SiP: Higher Value Systems More Moore: Miniaturization 45nm 32nm 22nm 16 nm . . . V Beyond CMOS Moore’s Law & More ITRS public conference – San Francisco

  4. Why a More than Moore roadmap ? • ITRS has demonstrated value of roadmapping for CMOS • Identify pre-competitive research domains, enabling cooperation between industries, institutes and universities. • Sharing of R&D efforts • Reduction of development costs and time • Synchronization of the E&M community with the Manufacturing community • Increase resource efficiency through focus • Promote market growth and job creation • More than Moore roadmapping offers a similar but more challenging opportunity • Need to propose a roadmapping methodology • White paper ITRS public conference – San Francisco

  5. Process scenarii roadmap functions needed applications FOM designs and devices lead markets size, suitability designtools societal needs processes ITRS public conference – San Francisco

  6. Spring 2011 workshop Lighting drivers Energy drivers Automotive drivers Main MtM drivers

  7. Main MtM drivers (from workshop) ITRS Public Conference – San Francisco

  8. MtM roadmapping next steps • Cross TWG Study Group officially launched yesterday • A&P, MEMS, Design & System drivers, RF/AMS • 2nd MtM workshop during 2012 Spring meeting • April 25th, in the Netherlands • Each group of CTSG presents status of tables derived from the main drivers • Quarterly conf calls in-between • First one to be held October 10th, 5pm CET, 8am PST • Check on progress • Add/withdraw drivers • Extend CTSG membership ITRS public conference – San Francisco

  9. Spring 2011 workshop Lighting drivers Energy drivers Automotive drivers Main MtM drivers CTSG Individual TWG tables Individual TWG tables Individual TWG tables Individual TWG tables ITRS public conference – San Francisco

  10. Questions ? Feedback ? ITRS public conference – San Francisco
