  1. Analytic Use Cases and Deployment Resources

  2. Alert List • Motion Detection • Total motion in area • Moving objects in area • Directional Motion • Total movement within range of directions • Abandoned Bag • Optimized for bags • Parked Car • Optimized for vehicles • Object Removed • Specific object • Any object in region • Trip Wire • Variable width increases specificity • Region • Objects starting, stopping, entering or leaving regions • Camera Movement • Motion/Motion Stopped, Blocked

  3. Use Cases • Basic alerts are used to implement specific use cases • Person approaching border, Traffic incident, Gate activity, etc. • Basic alerts can be configured to trigger on objects / behaviors of specific description • Size, Speed, Color, Type, Duration of movement, etc • Basic alerts can be compounded to only fire on more complex behavior • One or more basic alerts in a specific sequence in some time period

  4. Motion Detection • Restrictions • High angle view, uniform or slowly varying lighting, objects (people) do not become completely still • Use Case Example • Area over-crowding • Trigger when 75% of region covered with people • Suitable image:

  5. Directional Motion • Restrictions • Activity level medium to low, objects do not significantly overlap in image, high angle view (45 degrees or better) • Use Case Example • Enter through Exit • Trigger if object path consistently moves wrong way through Exit • Suitable image:

  6. Abandoned Object • Restrictions • Object > x% of image • Object contrasts well with background • Object not occluded for > 20% of time or for > 5 seconds at any one time • Suitable Image:

  7. Region Alert • Restrictions: • Medium to low activity • Objects must not significantly overlap • Use Case example • Crowd forming • Trigger when >N people remain in region for >T seconds • Suitable image:

  8. Tripwire • Restrictions • Use Case example • Gate Activity • Triggers when person passes through a gate in either direction • Suitable Image:

  9. Parked Car

  10. Object Removed

  11. Camera Movement

  12. Forensic Search

  13. Required Personnel • Alert Adjudicators • # cameras per adjudicator (with calculations…) • Search Specialist • Expert in forensic search… • Local administrator • Trained to independantly handle events such as: • Excessive alerts from camera (enable / disable) • Camera home position lost • Minor changes to camera home position • Basic setup of new cameras & simple alerts • General system monitoring • Works with IBM to resolve major problems
