  1. Programmable Logic Devices Building the Case for Software-style Assurance Kalynnda Berens Kalynnda.Berens@grc.nasa.gov SAIC @ NASA Glenn Research Center

  2. What is Programmable Logic • Programmable Logic Controllers (PLC) • Programmable Logic Devices • Field Programmable Gate Array (FPGA) • Application Specific Integrated Circuit (ASIC) • System-on-chip (SOC) • Complex PLD (CPLD) • others SAIC @ NASA Glenn Research Center

  3. The Hardware/Software Boundary SOC Reconfig. Computing SAIC @ NASA Glenn Research Center

  4. Pushing the Limits • System-on-Chip (SOC) • Combine microprocessor/input/output, often FPGA for programmability • Reconfigurable Computing • Morphware, Configware, Flowware • In NASA Strategic Technology Plan • FPGAs • 30,000 to over a million gates • Complex interactions SAIC @ NASA Glenn Research Center

  5. Complexity • Types of faults • Incomplete specifications • Design and Implementation Errors (Common mode) • Unexpected or unanticipated combinations of valid operating states. • Unintended interactions • Unknown defects in tools (design or verification) SAIC @ NASA Glenn Research Center

  6. Hardware/Software Differences • Most PL cannot be changed once “burned” (programmed). FPGAs can be programmed on-the-fly. • Software execution is serial – one instruction after another • PL execution is parallel – multiple simultaneous signals and processes • PL designed, verified, tested by engineers SAIC @ NASA Glenn Research Center

  7. Assurance: Product and Process SAIC @ NASA Glenn Research Center

  8. Current PL Process • Design from system requirements • Functional Simulation • Includes “corner cases” • Testing (unit and system) • Simulation and unit test usually performed by design engineer • May perform code coverage measurement • Verification takes 70% of design task SAIC @ NASA Glenn Research Center

  9. NASA PL Assurance Activities – from the user’s point of view SAIC @ NASA Glenn Research Center

  10. NASA PL Assurance Activities – from QA’s point of view 1 Vendor or contractor 2 Safety personnel SAIC @ NASA Glenn Research Center

  11. What are others doing? • Hardware/software co-verification • Industry/Military practices still open issue – tough nut to crack • ESA – starting to address FPGA/ASIC through reports and guidance • FAA – DO-254 for Complex Electronic Hardware, calls for design process assurance SAIC @ NASA Glenn Research Center

  12. PL-related Standards and Guidelines • IEC-61508 - “Functional Safety of Electrical/Electronic/ Programmable Electronic Safety-related Systems” • DO-254 – “Design Assurance Guidelines for Airborne Electronic Hardware” • IEC-1131-3 – “PLC Programming Languages” • IEC-61511 – “Functional Safety - Safety Instrumented Systems For The Process Industry Sector” • IEE SEMSPLC – “Software Engineering Methods for Safe Programmable Logic Controllers” SAIC @ NASA Glenn Research Center

  13. PL-related Standards and Guidelines (continued) • European Space Agency • Space Product Assurance – ASIC Development • VHDL Modeling Guidelines • FPGA report • EWICS TC7 Guidelines for the use of Programmable Logic Controllers in Safety-related Systems SAIC @ NASA Glenn Research Center

  14. FAA and DO-254 • Complex Electronic Hardware includes FPGA, CPLD, and ASIC • DO-254 required for Levels A and B (highest criticality) • Defines Hardware Life-Cycle Processes: • Planning Process • Hardware Design Processes • Requirements, Design, Implementation, Production, Test • Validation Process • Verification Process • Configuration Management Process • Process Assurance • Certification Liaison Process SAIC @ NASA Glenn Research Center

  15. DO-254 at Langley • Case study on applying DO-254 to SPIDER1 • Implemented process assurance • monitoring the development activities to assure they are in accordance to plans • Placed conceptual design in CM • Used Formal Methods 1Scalable Processor-Independent Design for Electromagnetic Resilience SAIC @ NASA Glenn Research Center

  16. FPGA Lessons LearnedEuropean Space Agency, 2002 • Reviewed FPGA’s in ESA/NASA missions • Extensive use in critical systems with little thought to SEU • Design and verification by same individual • Insufficient verification due to inadequate stimuli selection • Test only – simulation often skipped • Non-engineers “blessing” design • FPGA’s are “the software of the hardware world” • Encourage engineers to quickly get to hardware test, ignoring good design practice SAIC @ NASA Glenn Research Center

  17. Safety-Related Complex Electronic Systems, 2000 • Simulation alone is not adequate. Exhaustive list of possible failures not possible. • Strengthen system/subsystem tests • Consider origin of faults • Errors of specification, design, production • Internal faults • External faults • Quality of vendor-supplied soft core or macro libraries is not guaranteed • Synthesis tools can generate faults • High fault coverage in test is mandatory SAIC @ NASA Glenn Research Center

  18. What do we know? • PLCs use software, just the purpose and language differ • FPGAs and other Programmable Logic devices are very complex • Process assurance provides additional value in conjunction with product assurance • Process assurance currently not applied to most PLD development SAIC @ NASA Glenn Research Center

  19. What don’t we know? • Industry and Military QA Best Practices • What level of process assurance is required • Who should do QA on programmable logic • Hardware QA • More likely to understand PL or quickly learn • Need to learn process assurance activities • Software QA • Familiar with process assurance • Would need to learn PL hardware and language • How to integrate process assurance in NASA • Software CMM implementation may provide guide SAIC @ NASA Glenn Research Center

  20. Software->Hardware Assurance • Inspection of HDL code and schematics • Validated as low-cost, high-probability of catching errors for hardware • Walkthroughs • Independent test team • Formal Methods • Complexity measurements • Traceability • Change impact analysis • CM tools and processes • Functional, code coverage analysis • QA monitoring of development process SAIC @ NASA Glenn Research Center

  21. Hardware->Software Assurance • Simulation, test beds are standard operating procedure • Testing against boundary conditions (“corner cases”) • Wide variety of available tools for verification SAIC @ NASA Glenn Research Center

  22. Next steps • Goal is not to provide the answers to how PL is assured, but to set the parameters for constructive discussion within NASA and provide a common information base • Issue Paper on this topic • Process Assurance guidance for Hw QA • PL/Hardware guidance for Sw QA SAIC @ NASA Glenn Research Center

  23. Please Take the Survey! http://osat-ext.grc.nasa.gov/rmo/plcsurvey If you have industry/military QA or engineering contacts, please email me at: Kalynnda.Berens@grc.nasa.gov SAIC @ NASA Glenn Research Center
