  1. TRANSISTORS

  2. TYPES OF TRANSISTORS • PNP TRANSISTORS • NPN TRANSISTORS • FIELD EFFECT TRANSISTOR ( F.E.T ) • UNI JUNCTION TRANSISTOR ( U.J.T ) • SILICON CONTROLLED RACTIFIER ( S.C.R )

  3. CONSTRUCTION TRANISTOR IS A CONNECTION OF TWO DIODES. • PNP TRANSISTOR :- N TYPE SEMI CONDUCTOR SANDWICH BETWEEN TWO P TYPE SEMI CONDUCTORS. • NPN TRANSISTOR :- P TYPE SEMI CONDUCTOR SANDWICH BETWEEN TWO NTYPE SEMI CONDUCTORS. • PNP & NPN TRANSISTOR HAS THREE TERMINAL ( NEXT PAGE )

  4. TERMINALS NAME ARE EMITTER, BASE & COLLECTOR • PNP & NPN TRANSISTOR ARE BIPOLAR TRANSISTORS (BJT) • TRANSISTOR IS SEMI CONDUCTOR DEVICE • TRANSISTOR MAKE FROM SILICON & GERANIUM SEMI CONDUCTOR MATERIAL

  5. FIELD EFFECT TRANSISTOR • F.E.T HAS THREE TERMINALS • THESE TERMINAL KNOWN AS GATE,DRAIN & SOURCE. • F.E.T IS UNI POLAR TRANSISTOR

  6. UNI JUNCTION TRANSISTOR • UJT HAS THREE TERMINALS • THESE TERMINAL KNOWN AS BASE 1, BASE 2 & EMITTER • U.J.T IS UNI POLAR TRANSISTOR

  7. SILICON CONTROLLED RACTIFIER • S.C.R HAS THREE TERMINALS • THESE TERMINAL KNOWN AS ANODE, CATHODE & GATE • S.C.R IS UNI POLAR TRANSISTOR.

  8. WORKING OF TRANSISTOR • PNP & NPN TRANSISTOR HAS TWO JUNCTION, EMITTER BASE JUNCTION & COLLECTOR BASE JUNCTION • F.E.T,S.C.R,U.J.T HAS ONE JUNCTION CURRENT FLOW IN FROM ONE JUNCTION & DIRECTION

  9. APPLICATION OF TRANSISTOR • AMPLIFIER • SWITCH • CONTROLLED PROCESS
