Parabolas

sylvie avatar
sylvie
22 diapositives · 598 Views · Jul 30, 2014

Parabolas. Definitions. Parabola – set of all points equidistant from a fixed line ( directrix ) and a fixed point ( focus ) Vertex – midpoint of segment from focus  to directrix . Axis of Symmetry : line through the focus and vertex Vertical Parabola Form : ( x – h) 2 = 4p(y – k)

Parabolas - slide 1
01 / 22Parabolas
1 / 17

Télécharger la présentation

Parabolas
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Parabolas

  2. Definitions • Parabola – set of all points equidistant from a fixed line (directrix) and a fixed point (focus) • Vertex – midpoint of segment from focus  to directrix. • Axis of Symmetry: line through the focus and vertex • Vertical Parabola Form: (x – h)2= 4p(y – k) • Horizontal Parabola form: (y – k)2 = 4p(x – h)

  3. VERTEX FOCUS FOCUS VERTEX DIRECTRIX DIRECTRIX VERTICAL PARABOLA HORIZONTAL PARABOLA Opens either up or down. Up if p > 0, down if p < 0. Opens either left or right. Right if p > 0, left if p < 0.

  4. p: distance from the vertex to the focus and from the vertex to the directrix Focal Chord – the line segment that goes through the focus, and has endpoints on the parabola. It’s length is 4p. Important note: The points on a parabola are symmetric across the Axis of Symmetry. So, if you know one point, you can find the other. 2p 2p p p

  5. Ex 1: Write the equation of the parabola in standard form.

  6. Decide whether the parabola has vertical or horizontal axis of symmetry, and tell which way the graph opens. 2. -6x2= 3y 3. (y – 4)2 = 3x + 1 4. 2y = (x + 1)2 HINT: Which variable is squared? Vertical Opens down Horizontal Opens right Vertical Opens up

  7. Given the following information, write the equation of the parabola 5. Vertex (-2, 5); p= -½; Vertical Axis of Symmetry 6. Vertex (1, -3); p = 1/8; Vertical Axis of Symmetry Write the formula, and fill in values Write the formula, and fill in values

  8. Given the following information, write the equation of the parabola 7.Vertex (6, -1); p = -1/12; Horizontal Axis of Symmetry 8. Vertex (-5, -7); p = 1; Horizontal Axis of Symmetry Write the formula, and fill in values Write the formula, and fill in values

  9. 9 Vertex: Focus: Directrix: Axis: Equation: (0,0) (0,3) y = -3 x = 0 What is p? So, 4p is…? Is this a horizontal or vertical parabola? Write the formula, and fill in values. 3 positive or negative? Why? Vertical

  10. Vertex: Focus: Directrix: Axis: Equation: (0,0) (-2, 0) x = 2 y = 0 10 What is p? Is this a horizontal or vertical parabola? Write the formula, and fill in values. 2 positive or negative? Why? Horizontal

  11. 11 Vertex: Focus: Directrix: Axis: Equation: (3,2) (3,1) y = 3 x = 3 What is p? Is this a horizontal or vertical parabola? Write the formula, and fill in values. 1 positive or negative? Why? Vertical

  12. Vertex: Focus: Directrix: Axis: Equation: (-4,2) (0,2) x = -8 y = 2 12 What is p? Is this a horizontal or vertical parabola? Write the formula, and fill in values. 4 positive or negative? Why? Horizontal

  13. 13. Find the Vertex, the Focus, the Directrix, and sketch the graph (3, -1) 3 Up (3, 2) y = -4 What is the vertex? What is p? Which way does the graph open? Where is the focus? Where is the directrix? Sketch the graph.

  14. 14. Find the Vertex, the Focus, the Directrix, and sketch the graph (3, 5) -1 Left (2, 5) x = 4 What is the vertex? What is p? Which way does the graph open? Where is the focus? Where is the directrix? Sketch the graph.

  15. 15. Find the equation if… The Vertex is (-3, 6), and the Focus is (5, 6) What do we need for the equation? We need the vertex (GOT IT!) and p. Draw a sketch. How far away from the vertex is the focus? 8 Positive or Negative? Therefore, p = 8 and 4p = 32 So, the equation is:

  16. 16. Find the equation if… The Vertex is (2, -1), and the Directrix is x = 5 What do we need for the equation? We need the vertex (GOT IT!) and p. Draw a sketch. How far away from the vertex is the directrix? 3 Positive or Negative? Therefore, p = -3 and 4p = -12 So, the equation is:

  17. 17. Find the equation if… The Directrix is y = 5, and the Focus is (-3, 1) What do we need for the equation? We need the vertex and p. Draw a sketch. Where is the vertex in relation to the focus and directrix? Halfway in between Therefore, the vertex is at (-3, 3) Opens up or down? Therefore, p = -2 and 4p = -8 So, the equation is: Down

  18. How does a Parabola Work? Anything entering the parabola is reflected to the focus, concentrating the signal.

  19. How does a Parabola Work? Anything leaving from the focus reflects off the parabola in a straight line creating a beam.

  20. 18. Where are Parabolas used?

  21. Where are Parabolas used? Cars - headlights Sports – the trajectory of a ball

  22. Where are Parabolas used? Communication – a microphone Architecture – the St. Louis Arch
