  1. Chapter 6 Multiple Forms

  2. Multiple Forms • Multiple forms • Show and Hide methods for forms • Standard code modules • Variable scope in multiform projects • An AboutBox form • Splash screen • Set the startup form

  3. Multiple Forms • Creating new forms • Adding and removing forms • Hide & Show methods • Load & Unload statements • Referring to objects in other forms • code in one form cannot “see” obj. in other forms • reference: FormName!ObjectName.property

  4. Multiple Forms • First form is startup form. • By default, it is the first one created • You can set startup form in Project, Properties • Create form: • Project, Add Form • Select form type • You can add a form to project from existing form

  5. Adding/Removing Forms • All the information in a form resides with the form: controls, properties, code, variables • Add existing form: Project, Add Form and then click the existing tab • Remove a form: Project, Remove File

  6. Hide and Show methods • You display a form with the show method: frmAbout.Show • General form is formname.Show <style> • where style can be 1 (modal) or the default value 0 (nonmodal) • User must respond to Modal form & cannot click another form in same project • Hide a form: frmAbout.Hide

  7. Form Load & Activate Events • The first time a form is displayed, it triggers a form load event followed by a form activate event • Load calls the module into memory • Activate occurs when the form receives control • Subsequently, activate but not load events trigger when form is shown

  8. Unload/Load Statements (cont'd) • Only time you might want to load a form is when you want to load a form but display it later. • The Me keyword refers, always, to the currently active form: Unload Me Me.Hide

  9. Referring to Other Forms’ Objects • You can refer to txtName in another form called frmSummary this way: frmSummary!txtName = … or frmSummary!txtName.Font.Name = ... • This implies that control names are unique within a form but need not be unique across forms.

  10. Standard Code Modules • Public procedures are“visible” to all forms • Public variables are visible to all forms • SCM (Standard Code Module) has the extension .BAS • Create SCM: Project, Add Module • DIM variables in the code module are visible to all procedures in the module, but not to procedures in the form modules.

  11. Variables & Constants in Multi-form Projects • Scope of variables: • Local: available inside a procedure • Static: inside procedure, but remembered • Module level: available anywhere in a form • Global: available across forms--anywhere • Global variables declared with Public • Variable prefix naming conventions: m for module, g for global • Scope a variable as narrowly as possible

  12. An About Box • Acts like a Windows Help|About box • Often displays information about the programmers, designers, and so on • An about box is simply a modal form with an OK button and label boxes displaying information • You can use VB’s About Dialog template

  13. A Splash Screen • Splash screen displays while product loads • Create: Project, Add Form, then select Splash Screen • Splash screen loads first instead of main form • Place splash screen load statement in Sub Main procedure in Standard Code Module

  14. Setting the Startup Form/Proc. • By default, the first form you create in a project is the startup form • You can set the startup form in the Project Properties menu (Project menu)

  15. Hands on Programming Example • Programming example is a multi-form Coffee Sales example with these forms: • Splash screen • Main form • Summary form • About box • Main form called from splash screen

  16. Programming Hints • Make form run maximized window by setting the WindowState form property to 2-Maximized • In design time, close extra windows to maximize your view of form • Clicking a form's Close button halts execution

  17. Summary (1) • Projects can have unlimited # forms • First form displayed is the startup form • You can use forms from one project in another one • Show/Hide are form methods • Modal form requires a response; and, execution halts until response received

  18. Summary (2) • Load statement loads forms but does not display them • Me refers to currently active form • Refer to object in another form with form name as prefix • SCM contains public variables and public sub procedures that are global to project

  19. Summary (3) • Public can appear only in the General Declarations section of a module—place it in Standard Code Module only by convention • Static variables are local but with “memory” • Program execution can begin in a sub procedure called Main located in Standard Code Module
