  1. Static analysis for security Luis Sierra November, 2007 Stic AmSud - ReSeCo Workshop Montevideo, Uruguay

  2. Plan • Some motivation • Static analysis • PySTA: Python Static Analyzer • Permission usage analysis • Conclusions and further work

  3. Motivation • To understand and have experience of the permissions model of Besson, Dufay, and Jensen • Looking for a quick prototype • Moreover, I did not know Python

  4. [x := 2]1; [y := 4]2; [x := 1]3; [read (z)]4; if [z > x]5 then [z := y]6 else [z := x]7 Static analysis: example • Take a program S • Take a property P • Check if P holds in every possible execution of S • Checking at compile time • Approximate answers Every assignment is useful

  5. Pysta • 1 : set([]) • 2 : set(['y']) • 3 : ... [x := 2]1; [y := 4]2; [x := 1]3; [read (z)]4; if [z > x]5 then [z := y]6 else [z := x]7 Static analysis: example • Check if P holds in every possible execution of S • Checking at compile time Every assignment is useful

  6. [x := 2]1; [y := 4]2; [x := 1]3; [read (z)]4; if [z > x]5 then Om; [z := y]6 else [z := x]7 Static analysis: example • Take a program S • Take a property P • If Om does not terminate, we should delete assignment 2. Our analysis solves the halting problem !!! • Checking at compile time • Approximate answers Every assignment is useful

  7. The analyzer navigates in the control flow graph, collecting relevant information. This process must terminate

  8. Working list • The analyzer navigates in the CFG with an iterator • We exploit Python flexibility defining • an implementation with sets • and an implementation with lists

  9. Working list class workingList (object): def iter (self): pass def add (self, c): pass def MFP (a): W = WLmap [WLoption] (a.flow) for (l1, l2) in W.iter (): ... W.add ([(s,t) for (s,t) in ...]) ...

  10. Fix-point computation def MFP (a): W = WLmap [WLoption] (a.flow) for (l1, l2) in W.iter (): fl = a.transfer (l1) if (not a.latt.leq (fl, a.a [l2])): a.a [l2] = a.latt.join (a.a [l2], fl) W.add ([(s,t) for (s,t) in a.flow if s==l2]) a.dump ()

  11. A static analysis • The analysis is declared in the main program def analyze (file, analysisType): s = open (file + '.xml').read() p = parseString (s).documentElement a = analysisType (p) MFP (a)

  12. Some implementations • As well as with working lists, we implemented several static analysis • Live variables • Constraint propagation • Available expressions • Permission usage

  13. A class for analysis class MF (object): def __init__ (self, pgm, an): ... def defLattice (self): pass def defextremalValue (self): pass def transfer (self, l, s): pass def initialAnalysis (self): self.a = {} for l in self.Lab: self.a [l] = self.extremalValue \ if l in self.extremalLabel\ else self.latt.bottom () ...

  14. Live Variables Analysis class Analysis (MF): def __init__ (self, pgm): MF.__init__ (self, pgm, 'BW') def defLattice (self): self.latt = SetVarLat () def defextremalValue (self): self.extremalValue = SetVar ([]) def transfer (self, l): ... def kill (self, l): return SetVar (eval (getKill (self.Blocks[l]))) def gen (self, l): return SetVar (eval (getGen (self.Blocks[l])))

  15. Lattices • The information collected in a static analysis is good enough to provide • an operation of least upper bound (latt.join) • a comparison (latt.leq) • We are not interested in proving that a structure is a lattice, but in implementing quickly the relevant operations

  16. A lattice class lattice (object): def U (self): """Support set of the lattice. Meaningful if the support set is finite.""" pass def join (self, a, b): """Join operation: returns a new object with value in the lattice.""" pass def leq (self, a, b): """Less or equal relation: returns True or False.""" pass def bottom (self): """Bottom: returns a new object """ pass

  17. A library of lattices class semilattice (object): ... ## a cartesian product using tuples class cartesianProduct (lattice): ... ## a function space class functionspace (lattice): ... ## a function using a dictionary class genFunction (object): ... class newbottom (lattice): ... class powerset (lattice): ... class dual (lattice):

  18. 1 0  Multiplicities and permissions

  19. Permissions lattice

  20. Permissions analysis class Analysis (MF): ... def defLattice (self): self.latt = Perm (self.Resources, self.Action, self.ResType) def defextremalValue (self): self.extremalValue = self.latt.bottom () def transfer (self, l): ... class Perm (functionspace): ...

  21. Permissions analysis class Res (powerset): ... class Act (powerset): ... class PermRT (newbottom): ... class Mult (lattice): ... class PermMult (cartesianProduct): ... class RTfunc (oneFunction): ... class Perm (functionspace): ...

  22. A program grant (http ('*'), read, inf) grant (https ('site'), read, 1) grant (file ('walletId'), read, 1) while ...: while ...: consume (http ('site'), read) if ...: consume (http ('*'), read) else: break consume (file ('walletId'), read) if ...: consume (http ('site'), read) else: grant (file ('walletVisa'), read, 1) consume (file ('walletVisa'), read) consume (https ('site'), read)

  23. PySTA .pgm AE, LV, PU, CP pgmtoxml .xml AE, LV, PU, CP analyze dump

  24. grant (http ('*'), read, inf) grant (https ('site'), read, 1) grant (file ('walletId'), read, 1) while True: while True: consume (http ('site'), read) if True: consume (http ('*'), read) else: break consume (file ('walletId'), read) if True: consume (http ('site'), read) else: grant (file ('walletVisa'), read, 1) consume (file ('walletVisa'), read) consume (https ('site'), read) <?xml version="1.0" ?> <pgm> <meta Actions="set(['read'])" Label="15" ResType="set(['http', 'file', 'https'])" Resources="set(['walletId', 'walletVisa', 'site'])"/> <main> <command gen="http * read inf" kill="" label="1"/> <command gen="https site read 1" kill="" label="2"/> <command gen="file walletId read 1" kill="" label="3"/> <loop breaks="[9]" label="4"> <loop breaks="[]" label="5">         </branch> </main> </pgm> 1  P1 2  P2 3  P3 4  ERROR 5  P4        

  25. Conclusions and further work • Python is a good tool for fast and modular programming • Compare the classes of PySTA with the Coq viewpoint • Program interesting examples • Modify the permissions model using ad hoc constructs • Program new analyses

  26. Bibliography • A Formal Model of Access Control for Mobile Interactive Devices. Frédéric Besson, Guillaume Dufay, and Thomas Jensen
