  1. LVSERIES

  2. THREE NEW STANDS • LV150 LV150A LV100D

  3. TWO NEW ILLUMINATORS • LV-U EPI LV-U EPI 2

  4. ONE NEW LAMPHOUSE • LH-50 • New 12V/50W Lamp • Brighter than LH100

  5. TWO NEW ERECT IMAGE TRINOCULAR BODY TUBES • Fixed 100/100 20 Degree • Tilting 5-20 Degree 100/0, 20/80

  6. ONE NEW NOSEPIECE • High Endurance • Motorized

  7. NEW PLAN FLUOR & CR OBJECTIVES • Two Series PL FL Available • Epi BF/DIC • Epi BF/DF/DIC • All New CR L Plan Epi Series

  8. THREE NEW STAGES • 3 x 2 with Glass & Slide Inserts • 6 x 4 with Glass Insert • 6 x 6 with Quick Release

  9. ONE NEW CONCEPT • Base & Stage Carrier • Column • Riser • Arm = VERSATILITY

  10. NOW FOR THE DETAILS

  11. STANDS • LV 150/150A Replaces the L150/L150A • 12V/50W Transformer • Optional Riser Block 35mm • Separate Stage Carriers (2 Types) • Max Sample Height 82mm w/block, standard stages • Max Sample Height 116.5mm w/block, Suruga stage • LV150A has Built-in RS232 for External Nosepiece Control • CAD Design for Improved Rigidity • ESD 1000V to 10V in 0.2 Seconds • Focus Travel 40mm

  12. LV150/LV150A

  13. STANDS • LV 100D Replaces ME600L • Accommodates up to 6 Inches Travel in Y Axis • Fly Eye Technology for Dia Illumination • 1.5 times brighter than ME600L • 12V/50W Epi/Dia Transformer • Up front Epi/Dia Switch • ND8 and NCB 11 Filters for Transmitted Light • Same Lamphouse for both Epi & Dia • Max Specimen Height 64mm w/Riser Block • Stand Rigidity Twice That of ME600L • Focus travel 30mm

  14. FLY-EYE LENS Fly-Eye lens technology forms multiple images of the filament to better fill the back aperture of the objective

  15. FLY-EYE LENS

  16. FLY-EYE LENS

  17. LV 100D

  18. LV-U EPI ILLUMINATOR • Same Performance Features as Current LU Epi • Accepts New 12V/50W lamphouse

  19. LV-U EPI ILLUMINATOR 2 • Four Position Turret • BF, DF and Two Fluor Positions • Up Front Knob has Fluor Shutter Position • Accepts TE Style Cubes • Auto UV Cut Filter and Diffuser in BF/DF • New Polarizer/Analyzer Set • Lambda Plate Available for Epi-Pol Applications • Accepts Fluorescence Light Balancer

  20. Lamphouse 50 • New 12V/50W Lamp • Approx. 1100 hrs Lamp Life • Integrated Rear Reflector • Improved Collector Lens • Light Output Brighter than LH100 • Same Lamphouse for Epi & Diascopic • Low Power Consumption

  21. STAGES • Superb Mechanical Feel with Precise Positioning • Stages are Three plate design • 3x2 and 6x4 include glass plates • Slide insert & ESD Plate for 3x2 • Adapter Ring for Simple Circular Stage • 6x6 Includes Quick Release Clutch and Fine X/Y Control

  22. NEW PLAN FLUOR OBJECTIVES • LU BD Plan Fluor 5X through 100X, BF/DF/DIC • LU EPI Plan Fluor 5X through 100X, BF/DIC • Extended UV Range for Fluorescence • Lower Cost • New LU CR objectives

  23. TRINOCULAR BODY TUBES • Erect Image • Accepts 22mm & 25mm FOV Eyepieces • New Photo Port Adapters • LV Tube for ISO & Phototube Adapters • 0.55x C Mount Adapter (Direct to Trinoc)

  24. LV-T TRINOCULAR BODY • ESD Compliant • 20Degree Inclination • 100/100 Beamsplitter

  25. LV-TT2 TRINOCULAR BODY • 5-20 Degree Tilting • 100/0, 20/80 Beamsplitter • Centerable Phototube • Reduced Cost

  26. NEW NOSEPIECE • High Endurance Motorized • 10 times more durable than previous • Simple Connection to Stand • ESD Compliant • OEM Opportunities

  27. PRICE COMPARISON • ME600L BD/DIC $23,791.00 • LV100D BD/DIC $22,611.00 • L150A BD $22,144.00 • LV150A BD $20,211.00 • L150 BF $12,653.00 • LV150 BF $12,600.00

  28. LET’S REVIEW • New Stands New Optics NEW VERSATILITY

  29. DIGITAL SIGHT 2Mv, 2MBW, 2MBWc

  30. New Lineup for Digital Sight DS-2Mv : （White Body) 2M Pixel Color CCD Camera DS-2MBW :（Black Body) 2M Pixel B&W CCD Camera DS-2MBWc :（Black Body) 2M Pixel Cooled B&W CCD Camera

  31. DS 2M SPECIFICATIONS • Chip Size 8.5mm x 6.8mm (~1/2 inch) (1.96 Meg Effective) • Larger Pixel size 4.4um (DS-5M 2/3 inch 3.4 um) • Relay Lens 0.55x recommended for DS-2M series • Supported CCD format 2M Full Frame 1600x1200 15fps 800 x 600 20fps 800 x 560 30fps Center Scan 800 x 560 30fps • File Format : BMP, JPEG (L1) 12BIT RAW (U1)

  32. DS 2M SPECIFICATIONS • High Sensitivity 1.4X > DS-5M • 2MBWc Cooled to –20°C below Ambient • 12 bit A/D Conversion • Exposure Time • 1/1000 to 60 seconds non cooled • 1/1000 to 600 seconds Cooled

  33. Flexibility All 2M Camera Heads are Compatible with both L1 & U1 Control Units DS-2Mv DS-L１ DS-2MBW DS-U１ DS-2MBWc

  34. QUESTIONS ???
